順芯半導體_CODEC產品清單
| Channel | Package | Maste | Master ClockNote1 | SNR(dB) | THD+N(dB) | Head Phone Amp | Speake | Line Driver | PLL | Special Funcation | Supply Voltage(V) | |
| ES8311 | 3x3 QFN-20 | Both | S/USB/NS | DAC 110 | DAC -80 | Yes | Yes | Noise reduction filter DAC DRC | 1.6 to 3.6 | |||
| ES8311Q | 1-ch DAC | 3x3 QFN-20 | Both | S/USB/NS | DAC 110 | DAC -80 | Yes | Yes | Noise reduction filter DAC DRC | 1.6 to 3.6 | ||
| ES8312 | 1-ch DAC 1-ch ADC | 4x4 QFN-28 | Both | S/USB/NS | DAC 110 ADC 100 | DAC -80 ADC -93 | Yes | Yes | Noise reduction filter DAC DRC, FM in | 1.6 to 3.6 | ||
| ES8316 | 2-ch DAC 1-ch ADC | 4x4 QFN-32 | Both | S/USB/NS | DAC 96 ADC 95 | DAC -83 | Yes (ground centered) | Yes | 3-band PEQ | 1.7 to 3.6 | ||
| ES8323S | 2-ch DAC 1-ch ADC | 4x4 QFN-28 | Both | S/USB | DAC 96 ADC 95 | DAC -83 ADC -85 | Yes | Yes | 1.7 to 3.6 | |||
| ES8336 | ||||||||||||
| ES8374 | 1-ch DAC 1-ch ADC | 4x4 QFN-28 | Both | S/USB/NS | DAC 96 ADC 95 | DAC -83 ADC -85 | Yes | Class D | Yes | Yes | Noise reduction filter | 3 to 5.5 |
| ES8388 | 2-ch DAC 2-ch ADC | 4x4 QFN-28 | Both | S/USB | DAC 96 ADC 95 | DAC -83 ADC -85 | Yes | Yes | 1.5 to 3.6 | |||
| ES8388S | 1-ch DAC 1-ch ADC | 4x4 QFN-28 | Both | S/USB | DAC 96 ADC 95 | DAC -83 ADC -85 | Yes | Yes | 1.7 to 3.6 | |||
| ES8396 | 2-ch DAC 2-ch ADC | 6x6 QFN-48 | Both | S/USB/NS | DAC 96 ADC 95 | DAC -83 ADC -85 | Yes (ground centered) | Class D | Yes | Yes | Dual I2 S/PCM 6-band PEQ | 1.7 to 3.6 |
更多產品信息及試用
請至在線留言中，告訴我們您所需要的產品和其他相關信息，我們會盡快將資料及產品發給您！
研尚產品可提供的部分產品列表
-
電源轉換： 升壓芯片、 降壓芯片、 LDO、 背光驅動
-
電源管理： 鋰電池充電管理、 鋰電池保護、 QC快充協議、 OVP/OCP、 電壓檢測、 復位芯片、 PMU、 顯示屏電源芯片、 MOSFET、 ESD
-
馬達驅動： 步進電機/無刷&有刷
-
其它芯片： 運算放大器、 OSD
